4 Station Private Compact Floor Plan Restroom Trailer - ECO Series

Description

NEW! *Photos Coming Soon!*

The ECO Series 4 station compact restroom trailer was designed for special events or job sites where private cabins are desired. We recommend using this trailer for events that have an expected guest count of 250 people or less.

Standard Features:

Chassis:
  • Steel frame
  • 2-5/16" coupler with tongue jack
  • 7,000 lb. axle with electric brakes, ex lube
  • 16" radial tires and 8 hole steel wheels
Exterior Features:
  • 24" entrance doors
  • 24" mechanical room door
  • 24" fold out stairs with railing
Interior Features:
  • One piece vinyl flooring
  • Seamless gel-coated fiberglass interior / exterior walls
  • One piece gel-coated fiberglass ceiling / roof
  • White aluminum trim
  • Mirror over vanities
  • HDPE vanities
  • Toilet paper dispenser (double roll)
  • Paper towel dispenser - stainless
Electrical:
  • 13,500 BTU A/C with insulated ducts and registers
  • 5,000 BTU heat strip with insulated ducts and registers
  • Converter with charge protection - 30 AMP
  • LED DOT safety lights
  • LED interior lighting
  • LED Porch lights
  • 15’- 12 gauge power cord with 20 amp plug
  • Individually fused 4 gang switch panel
Plumbing:
  • Stainless steel sinks
  • Delta metered faucets
  • Dometic 410 white china toilets with foot flush
  • City water connection, 3/4" garden hose connection
  • Water lines inside of the trailer are weather protected
  • All toilets and sinks are individually valved
  • 350 Gallon 1/2" Co-Poly waste tank
  • 3" dump valve with quick connect

Specifications

No. of Stations Womens -2, Mens -2
Box Size 12'3" x 91"
Weight 4,640 lbs. (will vary based on features)
Weight (Axle) Single 7,000 lb.
Length w/ tongue 16'3"
Width of trailer
Width w/ stairs open		 7' 6"
11'
Height w/ AC 11'7"
Fresh Water Tank 105 Gallons (option)
Waste Tank 350 Gallons
Power Requirements One dedicated 120 Volt-20 amp circuit (will vary based on features)
No. of AC Units 1
